VgMyRouteCreator Class Reference

Interface for Objects responsible for the route creations. More...

Inheritance diagram for VgMyRouteCreator:

Public Types
enum	RoutePoint { eStart, eEnd }

Public Member Functions
virtual bool	setRoutePoint (RoutePoint pPoint, const std::string &pPlaceID)=0
	Sets a RoutePoint to a specific place. More...
virtual bool	setRoutePoint (RoutePoint pPoint, const VgEngine::VgPosition &pPosition)=0
	Sets a RoutePoint to a position within the map. More...
virtual void	resetRoutePoint (RoutePoint pPoint)=0
	Resets the place ID associated with a point. More...
virtual bool	isRoutePointSet (RoutePoint pPoint)=0
virtual void	computeRoute ()=0
	Computes a route. More...
virtual VgRoutingModule::VgIRouteRequestParameters *	editRoutingRequestParameters ()=0
	Returns a reference to the routing request parameters that computeRoute uses. More...
virtual void	resetRoutingRequestParameters ()=0
	Resets the routing request parameters to their initial state. More...
virtual VgEngine::VgRefPtr < VgEngine::VgAnimationDescriptor >	getRoutePointHighlightAnimationDescriptor ()=0
	Returns the descriptor of an animation intended to emphasize routing points. More...
virtual void	setAvoidStairs (bool pDisabledFriendly)=0
	Sets up the routing request parameters to include/exclude non disabled-friendly attributes. More...
virtual void	setRouteStyle (VgMyRouteStyler::RouteStyle pRouteStyle, bool pRecomputeRoute=true)=0
virtual VgMyRouteStyler::RouteStyle	getRouteStyle () const =0

Detailed Description

Interface for Objects responsible for the route creations.

Member Enumeration Documentation

enum VgMyRouteCreator::RoutePoint

Enumerator
eStart
eEnd

Member Function Documentation

virtual void VgMyRouteCreator::computeRoute ( )

pure virtual

Computes a route.

Remarks

Works only if both end points are set.

Implemented in VgMyBasicApplicationController.

virtual VgRoutingModule::VgIRouteRequestParameters* VgMyRouteCreator::editRoutingRequestParameters ( )

pure virtual

Returns a reference to the routing request parameters that computeRoute uses.

Returns

a reference to the routing request parameters to be used on the next computeRoute.

Implemented in VgMyBasicApplicationController.

virtual VgEngine::VgRefPtr< VgEngine::VgAnimationDescriptor > VgMyRouteCreator::getRoutePointHighlightAnimationDescriptor ( )

pure virtual

Returns the descriptor of an animation intended to emphasize routing points.

Implemented in VgMyBasicApplicationController.

virtual VgMyRouteStyler::RouteStyle VgMyRouteCreator::getRouteStyle ( ) const

pure virtual

Implemented in VgMyBasicApplicationController.

virtual bool VgMyRouteCreator::isRoutePointSet ( RoutePoint  pPoint )

pure virtual

Parameters

pPoint

RoutePoint to test.

Returns

True if the specified point is already set.

Implemented in VgMyBasicApplicationController.

virtual void VgMyRouteCreator::resetRoutePoint ( RoutePoint  pPoint )

pure virtual

Resets the place ID associated with a point.

Parameters

pPoint

RoutePoint to reset.

Implemented in VgMyBasicApplicationController.

virtual void VgMyRouteCreator::resetRoutingRequestParameters ( )

pure virtual

Resets the routing request parameters to their initial state.

Implemented in VgMyBasicApplicationController.

virtual void VgMyRouteCreator::setAvoidStairs ( bool  pDisabledFriendly )

pure virtual

Sets up the routing request parameters to include/exclude non disabled-friendly attributes.

Parameters

pDisabledFriendly

True if disabled friendly routing is wanted, false if not

Implemented in VgMyBasicApplicationController.

virtual bool VgMyRouteCreator::setRoutePoint ( RoutePoint  pPoint, const std::string &  pPlaceID  )

pure virtual

Sets a RoutePoint to a specific place.

Parameters

pPoint	RoutePoint to set
pPlaceID	Place to associates with pPoint.

Returns

False if the specified placeID is not routable.

Implemented in VgMyBasicApplicationController.

virtual bool VgMyRouteCreator::setRoutePoint ( RoutePoint  pPoint, const VgEngine::VgPosition &  pPosition  )

pure virtual

Sets a RoutePoint to a position within the map.

Finds the closest routing node from the routing network to the given position.

• pPosition.getMZOrAltitude() is used to determine what layer the position is associated to.
• Use the method VgMapModule::VgIMapModule::getHeightRangeForLayer() to find the appropriate altitude value for pPosition. For example:

  ...
  double lFloorHeight = 0.0;

  float pHeightMax;
  float pHeightMin;
  std::sring lLayerName = "0";
  if ( mMapModule->getHeightRangeForLayer(pLayer, pHeightMax, pHeightMin))
  {
      lFloorHeight = ((pHeightMax + pHeightMin) / 2);
  }

  lPosition.mZOrAltitude = lFloorHeight;
  ...

  Parameters

  pPoint	RoutePoint to set
  pPosition	Position to associates with pPoint.

  Returns

  False if the pPosition is not routable.

Implemented in VgMyBasicApplicationController.

virtual void VgMyRouteCreator::setRouteStyle ( VgMyRouteStyler::RouteStyle  pRouteStyle, bool  pRecomputeRoute = true  )

pure virtual

Implemented in VgMyBasicApplicationController.

---

The documentation for this class was generated from the following file:

• VgMyRouteCreator.h
