VgMyBasicApplicationController Class Reference

Implements a basic logic to handle the map display & behaviour. More...

Inheritance diagram for VgMyBasicApplicationController:

Public Member Functions
	VgMyBasicApplicationController (VgApplication::VgIApplication &pApplication, VgMyTextureLoader *pTextureLoader)
virtual	~VgMyBasicApplicationController ()
bool	loadConfiguration (const std::string &pConfiguration, const unsigned int pSecretKey, const std::string &pLicenseURL, const int pDataset=0)
void	unloadConfiguration ()
void	setLayerAndCameraHandler (VgMyLayerAndCameraHandler *pHandler)
void	setRouteCreator (VgMyRouteCreator *pCreator)
VgMyRouteCreator *	getRouteCreator () const
void	addRouteDisplay (VgMyRouteDisplay *pDisplay)
void	setNavigationCreator (VgMyNavigationCreator *pCreator)
void	addInstructionDisplay (VgMyInstructionDisplay *pDisplay)
void	addNavigationListener (VgMyNavigationListener *pListener)
	Add navigation listener in order to receive navigation related notifications. More...
void	removeNavigationListener (VgMyNavigationListener *pListener)
	Add navigation listener in order to receive navigation related notifications. More...
bool	has3DModule () const
bool	hasMapModule () const
bool	hasRoutingModule () const
bool	hasNavigationModule () const
void	addLayerAndCameraListener (VgMyLayerAndCameraListener *pListener)
void	deleteRoute ()
bool	setRoutePoint (VgMyRouteCreator::RoutePoint pPoint, const std::string &pPlaceID)
	Implementation of interface : VgMyRouteCreator. More...
bool	setRoutePoint (VgMyRouteCreator::RoutePoint pPoint, const VgEngine::VgPosition &pPosition)
	Sets a RoutePoint to a position within the map. More...
void	resetRoutePoint (VgMyRouteCreator::RoutePoint pPoint)
	Resets the place ID associated with a point. More...
bool	isRoutePointSet (VgMyRouteCreator::RoutePoint pPoint)
void	computeRoute ()
	Computes a route. More...
VgRoutingModule::VgIRouteRequestParameters *	editRoutingRequestParameters ()
	Returns a reference to the routing request parameters that computeRoute uses. More...
void	resetRoutingRequestParameters ()
	Resets the routing request parameters to their initial state. More...
VgEngine::VgRefPtr < VgEngine::VgAnimationDescriptor >	getRoutePointHighlightAnimationDescriptor ()
	Returns the descriptor of an animation intended to emphasize routing points. More...
void	setAvoidStairs (bool pDisabledFriendly)
	Sets up the routing request parameters to include/exclude non disabled-friendly attributes. More...
void	setRouteWidth (float pWidth)
	Determines the width of the created route. More...
void	setRouteMarkerHeight (float pHeight)
	Set route marker height. More...
void	layerWillChangeFrom (VgMyLayerAndCameraHandler *pSender, const std::string &pFloorFrom, const std::string &pFloorTo)
void	layerChangedTo (VgMyLayerAndCameraHandler *pSender, const std::string &pFloorFrom, const std::string &pFloorTo)
void	viewWillChange (VgMyLayerAndCameraHandler *pSender, const bool pDoesChangeFromGlobalToDetailed)
void	viewDidChange (VgMyLayerAndCameraHandler *pSender, const bool pDoesChangeFromGlobalToDetailed)
void	goToInstruction (const unsigned int pInstructionIndex)
bool	isGlobalView ()
void	switchToGlobalView (bool pIsAnimated=true)
void	switchToDetailedView (bool pIsAnimated=true)
const std::string &	getFocusedLayerName ()
void	gotoLayer (const std::string &pLayerName, bool pIsAnimated=true)
void	gotoLayer (const unsigned int pLayerIndex, bool pIsAnimated=true)
unsigned int	getNumberOfLayers ()
bool	getLayerName (const unsigned int pLayerIndex, std::string &pLayerNameOut)
void	gotoViewpoint (const VgEngine::VgIViewPoint &pViewPoint, const std::string &pLayerName, bool pIsAnimated=true)
void	gotoLookAtPosition (const VgEngine::VgPosition &pPosition, const std::string &pLayerName, bool pIsAnimated=true)
void	refreshParameters (unsigned int pWidth, unsigned int pHeight)
virtual void	notifyRouteComputed (VgRoutingModule::VgRouteRequestStatus pStatus, VgEngine::VgRefPtr< VgRoutingModule::VgIRoute > const &pRoute)
virtual bool	notifyNavigationComputed (VgNavigationModule::VgNavigationRequestStatus pStatus, VgEngine::VgRefPtr< VgNavigationModule::VgINavigation > const &pNavigation)
virtual void	notifyPositionUpdated (VgEngine::VgConstRefPtr< VgNavigationModule::VgINavigation > const &pNavigation, const VgEngine::VgPosition &pPosition, double pTime)
virtual void	notifyNewInstruction (VgEngine::VgConstRefPtr< VgNavigationModule::VgINavigation > const &pNavigation, unsigned int pIndex)
virtual void	notifyPositionDidChange (const std::string &pProvider, const VgEngine::VgPosition &pPosition)
virtual void	notifyFloorDidChange (const std::string &pProvider, const std::string &pFloor)
virtual void	notifyAccuracyDidChange (const std::string &pProvider, double pAccuracy)
virtual void	notifyContextDidChange (const std::string &pProvider, int pContext)
virtual void	notifyHeadingDidChange (const std::string &pProvider, double pHeading)
virtual void	notifyStatusDidChange (const std::string &pProvider, int pStatus)
virtual void	notifyLocationProviderEnabled (const std::string &pProvider)
virtual void	notifyLocationProviderDisabled (const std::string &pProvider)
VgEngine::VgRefPtr < VgRoutingModule::VgIRouteCallback >	getRouteCallback ()
void	setRouteStyle (VgMyRouteStyler::RouteStyle pRouteStyle, bool pRecomputeRoute=true)
	Change the routing style of lines generated by the routing helper. More...
VgMyRouteStyler::RouteStyle	getRouteStyle () const
	get the current route style More...

Protected Member Functions
void	animateToInstruction (VgEngine::VgConstRefPtr< VgNavigationModule::VgINavigation > const &pNavigation, unsigned int pIndex)

Protected Attributes
VgApplication::VgIApplication &	mVgApplication
VgMyLayerAndCameraHandler *	mLayerAndCameraHandler
VgMyRouteCreator *	mRouteCreator
VgMyNavigationCreator *	mNavigationCreator
std::list < VgMyLayerAndCameraListener * >	mLayerAndCameraListeners
std::list< VgMyRouteDisplay * >	mRouteDisplays
std::list < VgMyInstructionDisplay * >	mInstructionsDisplays
std::list < VgMyNavigationListener * >	mNavigationListeners
VgEngine::VgRefPtr < VgRoutingModule::VgIRoute >	mRoute
	Current Route of NULL if no route request succeed. More...
VgEngine::VgRefPtr < VgNavigationModule::VgINavigation >	mNavigation
	Current Navigation of NULL if no route request succeed. More...
unsigned int	mMaximumInstructionNumber
VgMyTextureLoader *	mTextureLoader
VgEngine::VgRefPtr < VgMyBasicRouteCallback >	mRouteCallback
VgEngine::VgRefPtr < VgMyBasicNavigationCallback >	mNavigationCallback
VgEngine::VgRefPtr < VgMyBasicNavigationListener >	mNavigationListener
std::string	mCurrentPhysicalFloor
	Used in conjuction with a position provider. More...
VgEngine::VgPosition	mCurrentPhysicalPosition
	Current physical position. More...

Additional Inherited Members
Public Types inherited from VgMyRouteCreator
enum	RoutePoint { eStart, eEnd }
	The points that a route may have. More...

Detailed Description

Implements a basic logic to handle the map display & behaviour.

This helper class eases the common operations onto maps. Customize it at will to fit your own application.

This controller inherits from main listeners to act as a dispatcher. All objects related to the map management should somehow be registred to this controller.

Constructor & Destructor Documentation

VgMyBasicApplicationController::VgMyBasicApplicationController	(	VgApplication::VgIApplication &	pApplication,
		VgMyTextureLoader *	pTextureLoader
	)

virtual VgMyBasicApplicationController::~VgMyBasicApplicationController ( )

virtual

Member Function Documentation

void VgMyBasicApplicationController::addInstructionDisplay

(

VgMyInstructionDisplay *

pDisplay

)

void VgMyBasicApplicationController::addLayerAndCameraListener

(

VgMyLayerAndCameraListener *

pListener

)

void VgMyBasicApplicationController::addNavigationListener

(

VgMyNavigationListener *

pListener

)

Add navigation listener in order to receive navigation related notifications.

Parameters

pListener

Navigation listener to receive

void VgMyBasicApplicationController::addRouteDisplay

(

VgMyRouteDisplay *

pDisplay

)

void VgMyBasicApplicationController::animateToInstruction ( VgEngine::VgConstRefPtr< VgNavigationModule::VgINavigation > const &  pNavigation, unsigned int  pIndex  )

protected

void VgMyBasicApplicationController::computeRoute ( )

virtual

Computes a route.

Remarks

Works only if both end points are set.

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::deleteRoute

(

)

VgRoutingModule::VgIRouteRequestParameters* VgMyBasicApplicationController::editRoutingRequestParameters ( )

virtual

Returns a reference to the routing request parameters that computeRoute uses.

Returns

a reference to the routing request parameters to be used on the next computeRoute.

Implements VgMyRouteCreator.

const std::string& VgMyBasicApplicationController::getFocusedLayerName

(

)

bool VgMyBasicApplicationController::getLayerName	(	const unsigned int	pLayerIndex,
		std::string &	pLayerNameOut
	)

unsigned int VgMyBasicApplicationController::getNumberOfLayers

(

)

VgEngine::VgRefPtr< VgRoutingModule::VgIRouteCallback > VgMyBasicApplicationController::getRouteCallback ( )

inline

References mRouteCallback.

VgMyRouteCreator* VgMyBasicApplicationController::getRouteCreator

(

)

const

VgEngine::VgRefPtr< VgEngine::VgAnimationDescriptor > VgMyBasicApplicationController::getRoutePointHighlightAnimationDescriptor ( )

virtual

Returns the descriptor of an animation intended to emphasize routing points.

Implements VgMyRouteCreator.

VgMyRouteStyler::RouteStyle VgMyBasicApplicationController::getRouteStyle ( ) const

virtual

get the current route style

Returns

current route style.

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::goToInstruction

(

const unsigned int

pInstructionIndex

)

void VgMyBasicApplicationController::gotoLayer	(	const std::string &	pLayerName,
		bool	pIsAnimated = true
	)

void VgMyBasicApplicationController::gotoLayer	(	const unsigned int	pLayerIndex,
		bool	pIsAnimated = true
	)

void VgMyBasicApplicationController::gotoLookAtPosition	(	const VgEngine::VgPosition &	pPosition,
		const std::string &	pLayerName,
		bool	pIsAnimated = true
	)

void VgMyBasicApplicationController::gotoViewpoint	(	const VgEngine::VgIViewPoint &	pViewPoint,
		const std::string &	pLayerName,
		bool	pIsAnimated = true
	)

bool VgMyBasicApplicationController::has3DModule

(

)

const

bool VgMyBasicApplicationController::hasMapModule

(

)

const

bool VgMyBasicApplicationController::hasNavigationModule

(

)

const

bool VgMyBasicApplicationController::hasRoutingModule

(

)

const

bool VgMyBasicApplicationController::isGlobalView

(

)

bool VgMyBasicApplicationController::isRoutePointSet ( VgMyRouteCreator::RoutePoint  pPoint )

virtual

Parameters

pPoint

RoutePoint to test.

Returns

True if the specified point is already set.

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::layerChangedTo	(	VgMyLayerAndCameraHandler *	pSender,
		const std::string &	pFloorFrom,
		const std::string &	pFloorTo
	)

void VgMyBasicApplicationController::layerWillChangeFrom	(	VgMyLayerAndCameraHandler *	pSender,
		const std::string &	pFloorFrom,
		const std::string &	pFloorTo
	)

bool VgMyBasicApplicationController::loadConfiguration	(	const std::string &	pConfiguration,
		const unsigned int	pSecretKey,
		const std::string &	pLicenseURL,
		const int	pDataset = 0
	)

virtual void VgMyBasicApplicationController::notifyAccuracyDidChange ( const std::string &  pProvider, double  pAccuracy  )

virtual

virtual void VgMyBasicApplicationController::notifyContextDidChange ( const std::string &  pProvider, int  pContext  )

virtual

virtual void VgMyBasicApplicationController::notifyFloorDidChange ( const std::string &  pProvider, const std::string &  pFloor  )

virtual

virtual void VgMyBasicApplicationController::notifyHeadingDidChange ( const std::string &  pProvider, double  pHeading  )

virtual

virtual void VgMyBasicApplicationController::notifyLocationProviderDisabled ( const std::string &  pProvider )

virtual

virtual void VgMyBasicApplicationController::notifyLocationProviderEnabled ( const std::string &  pProvider )

virtual

virtual bool VgMyBasicApplicationController::notifyNavigationComputed ( VgNavigationModule::VgNavigationRequestStatus  pStatus, VgEngine::VgRefPtr< VgNavigationModule::VgINavigation > const &  pNavigation  )

virtual

virtual void VgMyBasicApplicationController::notifyNewInstruction ( VgEngine::VgConstRefPtr< VgNavigationModule::VgINavigation > const &  pNavigation, unsigned int  pIndex  )

virtual

virtual void VgMyBasicApplicationController::notifyPositionDidChange ( const std::string &  pProvider, const VgEngine::VgPosition &  pPosition  )

virtual

virtual void VgMyBasicApplicationController::notifyPositionUpdated ( VgEngine::VgConstRefPtr< VgNavigationModule::VgINavigation > const &  pNavigation, const VgEngine::VgPosition &  pPosition, double  pTime  )

virtual

virtual void VgMyBasicApplicationController::notifyRouteComputed ( VgRoutingModule::VgRouteRequestStatus  pStatus, VgEngine::VgRefPtr< VgRoutingModule::VgIRoute > const &  pRoute  )

virtual

virtual void VgMyBasicApplicationController::notifyStatusDidChange ( const std::string &  pProvider, int  pStatus  )

virtual

void VgMyBasicApplicationController::refreshParameters	(	unsigned int	pWidth,
		unsigned int	pHeight
	)

void VgMyBasicApplicationController::removeNavigationListener

(

VgMyNavigationListener *

pListener

)

Add navigation listener in order to receive navigation related notifications.

Parameters

pListener

Navigation listener to receive

void VgMyBasicApplicationController::resetRoutePoint ( VgMyRouteCreator::RoutePoint  pPoint )

virtual

Resets the place ID associated with a point.

Parameters

pPoint

RoutePoint to reset.

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::resetRoutingRequestParameters ( )

virtual

Resets the routing request parameters to their initial state.

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::setAvoidStairs ( bool  pDisabledFriendly )

virtual

Sets up the routing request parameters to include/exclude non disabled-friendly attributes.

Parameters

pDisabledFriendly

True if disabled friendly routing is wanted, false if not

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::setLayerAndCameraHandler

(

VgMyLayerAndCameraHandler *

pHandler

)

void VgMyBasicApplicationController::setNavigationCreator

(

VgMyNavigationCreator *

pCreator

)

void VgMyBasicApplicationController::setRouteCreator

(

VgMyRouteCreator *

pCreator

)

void VgMyBasicApplicationController::setRouteMarkerHeight ( float  pHeight )

virtual

Set route marker height.

Adjust so that the marker appears to be anchored to the top of desired surface.

Parameters

pHeight

The height of the route markers in meters.

Implements VgMyRouteCreator.

bool VgMyBasicApplicationController::setRoutePoint ( VgMyRouteCreator::RoutePoint  pPoint, const std::string &  pPlaceID  )

virtual

Implementation of interface : VgMyRouteCreator.

Implements VgMyRouteCreator.

bool VgMyBasicApplicationController::setRoutePoint ( VgMyRouteCreator::RoutePoint  pPoint, const VgEngine::VgPosition &  pPosition  )

virtual

Sets a RoutePoint to a position within the map.

Finds the closest routing node from the routing network to the given position.

• pPosition.getMZOrAltitude() is used to determine what layer the position is associated to.
• Use the method VgMapModule::VgIMapModule::getHeightRangeForLayer() to find the appropriate altitude value for pPosition. For example:

  ...
  double lFloorHeight = 0.0;

  float pHeightMax;
  float pHeightMin;
  std::sring lLayerName = "0";
  if ( mMapModule->getHeightRangeForLayer(pLayer, pHeightMax, pHeightMin))
  {
      lFloorHeight = ((pHeightMax + pHeightMin) / 2);
  }

  lPosition.mZOrAltitude = lFloorHeight;
  ...

  Parameters

  pPoint	RoutePoint to set
  pPosition	Position to associates with pPoint.

  Returns

  False if the pPosition is not routable.

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::setRouteStyle ( VgMyRouteStyler::RouteStyle  pRouteStyle, bool  pRecomputeRoute = true  )

virtual

Change the routing style of lines generated by the routing helper.

Parameters

pRouteStyle	route style
pRecomputeRoute

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::setRouteWidth ( float  pWidth )

virtual

Determines the width of the created route.

Parameters

pWidth

The width of the route in meters

Implements VgMyRouteCreator.

void VgMyBasicApplicationController::switchToDetailedView

(

bool

pIsAnimated = true

)

void VgMyBasicApplicationController::switchToGlobalView

(

bool

pIsAnimated = true

)

void VgMyBasicApplicationController::unloadConfiguration

(

)

void VgMyBasicApplicationController::viewDidChange	(	VgMyLayerAndCameraHandler *	pSender,
		const bool	pDoesChangeFromGlobalToDetailed
	)

void VgMyBasicApplicationController::viewWillChange	(	VgMyLayerAndCameraHandler *	pSender,
		const bool	pDoesChangeFromGlobalToDetailed
	)

Member Data Documentation

std::string VgMyBasicApplicationController::mCurrentPhysicalFloor

protected

Used in conjuction with a position provider.

Records the last received floor change notification.

VgEngine::VgPosition VgMyBasicApplicationController::mCurrentPhysicalPosition

protected

Current physical position.

Note the altitude is relative to the ground, and not the current floor. So from this position it's possible to determine the floor.

std::list<VgMyInstructionDisplay*> VgMyBasicApplicationController::mInstructionsDisplays

protected

VgMyLayerAndCameraHandler* VgMyBasicApplicationController::mLayerAndCameraHandler

protected

std::list<VgMyLayerAndCameraListener*> VgMyBasicApplicationController::mLayerAndCameraListeners

protected

unsigned int VgMyBasicApplicationController::mMaximumInstructionNumber

protected

VgEngine::VgRefPtr< VgNavigationModule::VgINavigation > VgMyBasicApplicationController::mNavigation

protected

Current Navigation of NULL if no route request succeed.

Remarks

Only this controller delete this object

VgEngine::VgRefPtr< VgMyBasicNavigationCallback > VgMyBasicApplicationController::mNavigationCallback

protected

VgMyNavigationCreator* VgMyBasicApplicationController::mNavigationCreator

protected

VgEngine::VgRefPtr< VgMyBasicNavigationListener > VgMyBasicApplicationController::mNavigationListener

protected

std::list<VgMyNavigationListener*> VgMyBasicApplicationController::mNavigationListeners

protected

VgEngine::VgRefPtr< VgRoutingModule::VgIRoute > VgMyBasicApplicationController::mRoute

protected

Current Route of NULL if no route request succeed.

Remarks

Only this controller delete this object

VgEngine::VgRefPtr< VgMyBasicRouteCallback > VgMyBasicApplicationController::mRouteCallback

protected

Referenced by getRouteCallback().

VgMyRouteCreator* VgMyBasicApplicationController::mRouteCreator

protected

std::list<VgMyRouteDisplay*> VgMyBasicApplicationController::mRouteDisplays

protected

VgMyTextureLoader* VgMyBasicApplicationController::mTextureLoader

protected

VgApplication::VgIApplication& VgMyBasicApplicationController::mVgApplication

protected

---

The documentation for this class was generated from the following file:

• VgMyBasicApplicationController.h
