The Vg3DModule::VgIGeometry interface is used as an abstraction of geometric features that can be added to or removed from the scene. More...
Public Member Functions | |
| VgIGeometry () | |
| Constructor. More... | |
| virtual | ~VgIGeometry () |
| Destructor. More... | |
| virtual VgIGeometryType | getType () const |
| Gets the geometry type. More... | |
| virtual VgEngine::VgRefPtr < VgEngine::VgLayer > | getLayer () |
| virtual void | setLayer (VgEngine::VgRefPtr< VgEngine::VgLayer > pLayer, bool pHaveGeographicCoherence=true) |
| Sets the associated layer. More... | |
| virtual void | addListener (VgEngine::VgRefPtr< Vg3DModule::VgIGeometryCallback > pCallback) |
| Adds a listener to the geometry object. More... | |
| virtual void | removeListener (VgEngine::VgRefPtr< Vg3DModule::VgIGeometryCallback > pCallback) |
| Removes a listener from the geometry object. More... | |
| const VgEngine::VgVisibilityRamp | getVisibilityRamp () const |
| void | setVisibilityRamp (const VgEngine::VgVisibilityRamp &pRamp) |
| Sets the visibility ramp. More... | |
| const std::string & | getID () const |
| Vg3DModule::VgIGeometry * | asGeometry () |
| Casts this instance into a VgIGeometry. More... | |
| virtual Vg3DModule::VgPoint * | asPoint () |
| Casts this instance into a VgPoint. More... | |
| virtual Vg3DModule::VgLine * | asLine () |
| Casts this instance into a VgLine. More... | |
 Public Member Functions inherited from VgEngine::VgSpatial | |
| void | setAnimation (const std::string &pAnimationName, VgEngine::VgRefPtr< VgEngine::VgAnimation > &pAnimation) |
| Sets an animation on this spatial. More... | |
| void | setAnimation (VgEngine::VgRefPtr< VgEngine::VgAnimation > pAnimation) |
| Sets an animation with an empty name on this spatial. More... | |
| void | setLocalAnimation (VgEngine::VgRefPtr< VgEngine::VgAnimation > pAnimation) |
| Sets an animation on this spatial. More... | |
| VgConstRefPtr< VgAnimation > | getAnimation (const std::string &pName) const |
| Gets an animation from the spatial's animation map. More... | |
| VgRefPtr< VgAnimation > | editAnimation (const std::string &pName) |
| Edits an animation from the spatial's animation map. More... | |
| void | getAnimationNames (std::list< std::string > &pNameList) const |
| Gets the list of the stored animation names. More... | |
| VgEngine::VgPosition | getPosition () const |
| Gets spatial's position. More... | |
| virtual void | setPosition (const VgEngine::VgPosition &pPosition, bool pHaveGeographicCoherence=true) |
| Sets the spatial position. More... | |
| VgEngine::VgOrientation | getOrientation () const |
| Gets spatial's orientation. More... | |
| void | setOrientation (const VgEngine::VgOrientation &pOrientation) |
| Sets the spatial orientation. More... | |
| float | getScale () const |
| void | setScale (float pScale) |
| Sets the spatial's scale. More... | |
| int | getZIndex () const |
| void | setZIndex (int pZIndex) |
| Sets the Z Index. More... | |
| bool | isDrawnOnTop () const |
| void | setDrawOnTop (bool pEnable) |
| Sets the drawOnTop flag. More... | |
| virtual void | setVisible (bool pIsVisible) |
| Sets the visibility. More... | |
| virtual bool | isVisible () const |
| Public Member Functions inherited from VgEngine::VgReferenced | |
| VgReferenced () | |
| Constructor. More... | |
| VgReferenced (const VgReferenced &pThis) | |
| Copy constructor. More... | |
| virtual | ~VgReferenced () |
| Destructor. More... | |
| VgReferenced & | operator= (const VgReferenced &pThis) |
| Assignment operator. More... | |
| void | ref () const |
| This method is used to add a reference to this object. More... | |
| void | unref () const |
| This method is used to remove a reference to this object. More... | |
| int | getNbReferences () const |
| Retrieves the number of references to this object. More... | |
Friends | |
| class | VgEngine::VgObjectBridge |
Additional Inherited Members | |
| Protected Member Functions inherited from VgEngine::VgSpatial | |
| VgSpatial () | |
| Default constructor. More... | |
| virtual | ~VgSpatial () |
| Destructor. More... | |
| Protected Attributes inherited from VgEngine::VgSpatial | |
| Private * | mPrivate |
| Private. More... | |
| Protected Attributes inherited from VgEngine::VgReferenced | |
| int | mNbReferences |
| The number of references to this object. More... | |
The Vg3DModule::VgIGeometry interface is used as an abstraction of geometric features that can be added to or removed from the scene.
| Vg3DModule::VgIGeometry::VgIGeometry | ( | ) |
Constructor.
|
virtual |
Destructor.
|
virtual |
Adds a listener to the geometry object.
| pCallback | The callback to associate with this geometry object. |
|
virtual |
Casts this instance into a VgIGeometry.
Reimplemented from VgEngine::VgSpatial.
|
virtual |
Casts this instance into a VgLine.
Reimplemented from VgEngine::VgSpatial.
Reimplemented in Vg3DModule::VgPoint, and Vg3DModule::VgLine.
|
virtual |
Casts this instance into a VgPoint.
Reimplemented from VgEngine::VgSpatial.
Reimplemented in Vg3DModule::VgPoint, and Vg3DModule::VgLine.
| const std::string& Vg3DModule::VgIGeometry::getID | ( | ) | const |
|
virtual |
|
virtual |
Gets the geometry type.
Reimplemented in Vg3DModule::VgPoint, and Vg3DModule::VgLine.
| const VgEngine::VgVisibilityRamp Vg3DModule::VgIGeometry::getVisibilityRamp | ( | ) | const |
|
virtual |
Removes a listener from the geometry object.
| pCallback | The callback to disassociate from this geometry object. |
|
virtual |
Sets the associated layer.
| pLayer | The VgLayer to associate with the geometry object. Pass pLayer as null to disassociate the geometry object from a layer. |
| pHaveGeographicCoherence | An optional parameter who by default is true. Is used to determine the geographic coherence of the geometry. If set to false, then the geometry will be coherent with the scene. |
| void Vg3DModule::VgIGeometry::setVisibilityRamp | ( | const VgEngine::VgVisibilityRamp & | pRamp | ) |
Sets the visibility ramp.
|
friend |
